机床特点 Features of machine tools
1. 数控立式车床是一种性能良好、工艺范围广泛、生产效率高的先进
设备，适用于各行业的机械加工，可用于内外圆柱面、内外圆锥面、端
面、切槽、圆弧及各种回转曲面的粗、精加工。可根据客户要求配主轴
伺服电机和主轴编码器，可实现车螺纹和恒线速切削功能。
2. 工作台主轴采用了高精度可调径向间隙双列短圆柱滚子轴承定心。轴
向采用恒流静压导轨，使工作台具有旋转精度高、承载能力大、热变形
小的特点。
3. 底座、工作台、床体、横梁等大件采用了强度高、耐磨性能好的灰口铸铁并处理，消除内应力，不变形。
4. 床体、横梁、滑枕等导轨面采用淬火、磨削、人工合研，接触面好，精度高。横梁带液压时效锁紧，吃刀量大，不发颤。
5. 机床进给采用交流伺服电机、滚珠丝杠传动，横梁配有不锈钢封闭护罩，增加了机床的安全性、宜人性。
6. 机床的主传动由交流电机驱动、经 4 级主轴变速机构，实现了工作台的转速范围。
7. 数控系统根据用户需要，可选用进口或国产配置。
8. 标准配置：方滑枕和五角刀台任选一种。选择配置：电动刀台、半封闭罩壳、冷却排屑装置和侧刀架。

1. CNC vertical lathe is an advanced equipment with good performance, wide range of technology and high production efficiency. It is suitable for mechanical processing of various industries, and can be used for internal and external cylindrical surface, internal and external cone surface, end face, grooving Rough and finish machining of circular arc and various rotary surfaces. It can be equipped with spindle servo motor and spindle encoder according to customer requirements, which can realize thread turning and constant linear speed cutting function.
2. High precision adjustable radial clearance double row short cylindrical roller bearing is used for the spindle of the worktable. The constant current static pressure guide rail is adopted in the axial direction, which makes the worktable have the characteristics of high rotation accuracy, large bearing capacity and small thermal deformation.
3. The base, worktable, bed body, crossbeam and other large parts are made of gray cast iron with high strength and good wear  resistance, which eliminates internal stress and does not deform.
4. Quenching, grinding and manual grinding are adopted for the guide surface of bed body, beam and ram, with good contact  surface and high precision. Crossbeam with hydraulic aging locking, large cutting capacity, no chatter.
5. The machine tool is driven by AC servo motor and ball screw, and the crossbeam is equipped with stainless steel cover, which increases the safety and amenity of the machine tool.
6. The main drive of the machine tool is driven by AC motor, and the speed range of the worktable is realized through the 16 stage spindle speed changing mechanism.
7. The CNC system can be imported or domestic configuration according to the needs of users.
8. Standard configuration: either square ram or five corner turret. Optional configuration: electric cutter table, semi enclosed cover, cooling chip removal device and four speed stepless speed regulation.
